JBL Amplifier Mixer VMA 1120

Model: JBL Amplifier Mixer VMA 1120

Hãng: JBL/Mỹ (Chính Hãng, có CO-CQ)

Tập đoàn: Harman Pro

Xuất xứ: Trung Quốc

Bảo hành: 12 tháng, theo tiêu chuẩn Hãng SX

Giá bán: 19.600.000 vnđ

5 input channel with 1 output channel of 120W Mixer/Amplifier

Để biết thêm thông tin chi tiết về sản phẩm
Vui lòng liên hệ cho chúng tôi theo địa chỉ:
Email: phamhung@hdchanoi.com hoặc gọi điện
CSKH của HDC sẽ giúp bạn.
Tel: 0903445356 - - Tel/fax: 04. 3978 08 02

Thông tin sản phẩm
Thông số kỹ thuật

FEATURES

• 5 inputs with 1 output of 60, 120, or 240-watts of power

• Independent bass and treble controls for each output channel

• 100V and 70V output, or 4Ω/8Ω

• Paging Chime, and Priority muting

• Works with JBL CSR-V wall controllers

• Balanced mic/line inputs; RCA (.775V) inputs

• Rack mounting hardware included

SPECIFICATIONS

Max Output Power per Channel	into 4 Ω or 8 Ω; 1kHz, ≤ 0.5% THD - VMA160: 60W VMA1120: 120W VMA1240: 240W
Insertion Loss	(70V & 100V outputs) 1dB maximum
Number of Inputs	5
Number of Outputs	1
Tone Controls	(Bass and Treble non-detented potentiometers on each channel) Bass +/-14dB @ 50Hz; Treble +/-14dB @10kHz
Input Sensitivity	(to obtain full rated power into 8 Ω load) Mic Input: 5.5mVRMS Line Input: 1.3VRMS RCA Input (stereo in): 130mVRMS
Frequency Response	(measured at 2.83VRMS into rated load impedance at any output) 4/8 Ω Output: 20Hz - 20kHz, +/-2dB; 70V/100V Outputs: 80Hz - 15kHz +/-3dB
Total Harmonic Distortion (THD)	(measured at 2.83VRMS into rated load impedance at any output) Power Amp Output: <0.5%, 20Hz - 20kHz
Signal to Noise Ratio	(Ref. Rated Power, mixer levels @ min., master volume @ max. A-weighted) >76dB
Input Impedance	(nominal) Mic: 400 Ω Line: 20 kΩ (balanced) RCA: 50 kΩ
Phantom Power	27VDC
Crosstalk	(reference rated power, volume at mid position, 1kHz) -70 dB
Nominal AC Line Voltages	100V, 120V, 220V, 220-240V, 50/60 Hz
Minimum Load Impedance	(Low Impedance Output, 70V Output, 100V Output) VMA160: 4 Ω, 80 Ω,160 Ω VMA1120: 4 Ω, 40 Ω, 80 Ω VMA1240: 4 Ω, 20 Ω, 40 Ω
Operating Temperature/Humidity	0°C to 35°C @ 95% R.H. (non-condensing)
Storage Temperature	-20°C to 85°C
Net Weight	VMA160: 19.4 lb (8.8 kg) VMA1120: 20.2 lb (9.2 kg) VMA1240: 25.5 lb (11.6 kg)
Dimensions	Width: 17.0 in. (432 mm) Depth: 16.3 in. (415 mm) Height: 3.5 in. (88 mm)
Shipping Weight	VMA160: 24.6 lb (11.2 kg) VMA1120: 25.5 lb (11.6 kg) VMA1240: 30.8 lb (14 kg)
